Universal Testing Machine with 220V/50HZ Power 80×50×150cm Dimension and ASTM ISO EN JS Standard for Material Testing

Gambar besar : Universal Testing Machine with 220V/50HZ Power 80×50×150cm Dimension and ASTM ISO EN JS Standard for Material Testing

Detail produk:

Tempat asal:	Guangdong, Cina
Nama merek:	Liyi
Nomor model:	Liyi

Syarat-syarat pembayaran & pengiriman:

Kuantitas min Order:	1

Kontak

Universal Testing Machine with 220V/50HZ Power 80×50×150cm Dimension and ASTM ISO EN JS Standard for Material Testing

Deskripsi

Tipe daya:	Elektronik	Motor:	motor sevor panasonic
Metode operasi:	Operasi Windows Komputer	Opsi kapasitas:	5,10,20,50.100.200.500,1000,2000,5000kg Opsional
Stroke:	800mm (tidak termasuk perlengkapan)	Kecepatan tes:	0,5 ~ 500mm / mnt (kontrol dengan input keyboard)
Ketepatan:	0,5%	Resolusi:	1/250.000
Catu daya:	220V/50Hz atau 110V/60Hz	Ukuran:	8050150cm
Ruang tarik yang efektif:	1200mm (berisi genggaman)	Lebar uji efektif:	400mm, 320mm
Akurasi kecepatan:	Kurang dari ±0,5%	Akurasi perpindahan:	Kurang dari ±0,5%
Berat:	Sekitar 145 kg
Menyoroti:	220V/50HZ Power Universal Testing Machine , 80×50×150cm Dimension Universal Testing Machine , ASTM ISO EN JS Standard Universal Testing Machine

Liyi Universal Testing Machine

The Liyi tensile testing machine is designed for comprehensive material testing across multiple industries including aviation, aerospace, petroleum, chemical, machinery, metal materials, wire and cable, paper, packaging, textiles, pharmaceuticals, and food processing. This versatile equipment performs various tests including tensile, compression, bending, tearing, peeling, adhesion, and shear tests.

Key Features

Wide range of capacity options from 1N to 2000N
High precision measurement with 0.5% accuracy
Large effective test space (1200mm pull space)
Advanced servo motor system for precise control
Computer-controlled operation with comprehensive software
Customizable grips for various testing requirements

Technical Specifications

Model	LY-1066A	LY-1066B
Capacity	1,2,5,10,20,50,100,200,500,1000,2000N (optional/customizable)
Accuracy level	0.5%
Effective pull space	1200mm (including grips)
Effective test width	400mm	320mm
Test force resolution	1/250,000	1/150,000
Test Speed	0.1~500mm/min	50~500mm/min
Motor system	Panasonic servo motor + drive	AC motor + drive
Dimension	80×50×150cm
Weight	Approx. 145 kg
Power	1Ø, 220V/50HZ

Product Images

Company Profile

Dongguan Liyi Environmental Technology Co., Ltd is a high-tech production-oriented enterprise specializing in developing and manufacturing environmental testing equipment. With advanced technology, experienced personnel, and a comprehensive quality management system, we serve customers in over 150 countries.

Frequently Asked Questions

Are you the manufacturer? What about after-sales service and warranty?

Yes, we are a professional manufacturer with 12 months warranty and free maintenance. We provide technical support via email or video chat, with solutions typically offered within 24-48 hours of problem confirmation.

What is the delivery time?

Standard machines typically ship within 15-20 working days after deposit. We can arrange expedited shipping for urgent needs.

Do you accept customization and OEM services?

Yes, we offer both standard and customized machines, including OEM/ODM services with your logo.

How do I install and use the machine?

We provide English operation videos. Most machines ship fully assembled - just connect power to begin use. We can assist with on-site installation if needed.
