Detail produk:
|
Ketepatan: | ± 0,5% | Kekuatan: | 850w |
---|---|---|---|
Kelas Perlindungan: | IP56 | Voltase: | 220V, 380V, 240V, 110V |
Kapasitas kekuatan: | Maks 500kg | Motor: | Motor Servo Panasonic |
Stroke: | 850mm (dapat disesuaikan) | Resolusi: | 1/250.000 |
Catu daya: | 1PH, AC220V, 50/60Hz | Kecepatan tes: | 0,5 ~ 1000mm/mnt |
Rentang tes: | 400mm MAKSIMAL | Ukuran: | 80*50*150cm |
Berat: | 90kg | Sistem Operasi: | TM2101 |
Konsumsi daya: | 220V/50Hz atau 110V/60Hz | ||
Menyoroti: | 10KN 100KN Universal Testing Machine,Custom Hydraulic Tensile Strength Testing Machine,Steel Bar Rebar Material Testing Machine |
Capacity | 5,10,20,50,100,200,500,1000,2000,5000KG optional |
---|---|
Stroke | 800mm (not including fixture) |
Test Speed | 0.5~1000mm/min (control by keyboard input) |
Test Range | 400mm MAX |
Dimension | 80*50*150CM |
Weight | 90kg |
Accuracy | ±0.5% or better |
Operation Method | Computer control |
Resolution | 1/250,000 |
Motor | Panasonic servo motor |
Operation System | TM2101 |
Accessories | Customized clamps by appointment, force sensors, printer, and operation manual |
Power | 220V/50HZ or 110V/60HZ |
